High pressure polyurethane spray/injection equipment JHPK-H30
Product
description
- 产品描述
-
- Commodity name: High pressure polyurethane spray/injection equipment JHPK-H30
- Commodity ID: JHPK-H30
The lubricant inside the anti-solidifying lubricating cylinder circulates with high speed so that the leaked material and impurities could be brought away rapidly. The shaft for black material is always kept in the lubricant avoiding the crystallization.
Pneumatic high pressure polyurethane/polyurea spray equipmentJHPK-H30
Product Introduction
The equipment has obtained CE certification, safe and environmental protection.
Having the proprietary property rights in design and production,
several national patents have been applied and approved.
The perfect coaxial structure design of the horizontal booster pump
reduces greatly the abrasion of the sealing. There is no pressure
difference during operation and the commuting pressure fluctuation
value is ideal and stable.
The lubricant inside the anti-solidifying lubricating cylinder circulates with high speed so that the leaked material and impurities could be brought away rapidly. The shaft for black material is always kept in the lubricant avoiding the crystallization.
The delicate coupling structure is easy for the dismounting of the booster pump during the maintenance. When necessary, the complete unilateral raw material pump can be replaced to change the proportion of the raw material.
The pneumatic commuting control assembly is simple in structure and reliable in operation, and enables the pump body operating normally during the lack of electricity.
The design and application of the reset function when shut down realizes the dual protection.
The dual filters of the equipment for both high and low pressure and the filter of the nozzle realize the triple filtration protection for the raw material and reduce the blocking.
The special armoured temperature sensor inside the heater can collect the temperature signal at any time, hence the overshooting value for heating is well controlled.
Standard Configuration:
Main equipment: 1 set Spray gun: 1 piece Heating pipe: 15 meter 3m pipe connecting to the gun: 1 set Feeding pump: 2 sets Spare parts : 1 set Tools : 1 set English manual: 1 set Package: plywood tray Shipping Parameter:
Dimension: 1000mm*1000mm*1550mm Weight: 150Kg Technical Parameter
Proportion of raw material: 1：1 Viscosity range of raw material: 200-1000 CPS Output of raw material: 2-7.8L/min Heating power: 3000W*2 Hose heating power: 3500W Heating temperature range: 0℃～70℃ Electrical source: 3 phase 4 wire, 380V 50Hz Compressed air: 0.5～0.8Mpa（70~120psi）≥ 1m3/min Output pressure of raw material 5～13.8Mpa(725~2000psi) Max. length (optional): 90m(300ft)
Process / case
Company ProfileJHPK company's main products are polyurethane spraying machine, polyurea spraying machine, polyurethane foaming machine, polyurethane pouring equipment, polyurethane spraying equipment, polyurethane foaming material, polyurethane black and white material, polyurethane resin pultrusion equipment, epoxy resin pultrusion equipment, unsaturated Resin pultrusion equipment, broken bridge aluminum doors and windows filling equipment, polyurethane packaging equipment, feed pump, polyurethane spray gun, polyurethane insulation pipeline, polyurethane road maintenance and lifting equipment, automatic spraying equipment, laboratory polyurethane equipment, tube-in-tube foaming equipment, intelligent two-component spraying equipment, etc.
FAQAre you a factory? How large is the area? headquartered in Beijing, the production center moved to Weinan New District in Hebei in 2018; the production center covers an area of 63,000 square meters, about 100 acres. Is your equipment imported? The mechanical equipment produced by Jinghua Parker is composed of spare parts processed by the processing center imported from the United States, zero-matched by the domestic brand processing center, and Siemens, Schneider and other internationally renowned brand accessories. It is a pure domestic equipment and a national brand. Overseas sales are an important channel for sales of Jinghua Parker products, so the appearance of the equipment is relatively good-looking and is in line with the world. Equipment? Is it installed at home? Free delivery, free on-site installation and commissioning training services for customers in China; free export packaging services for export equipment Why is the product of Jinghua Parker recognized by the market/word of mouth? Because Jinghua Parker starts from the procurement of high-quality raw、 materials, independent processing of spare parts, strict implementation of quality inspection system, traceable finishing process, perfect product display and after-sales service of online and offline process communication, the customer is the core only to build A good mechanical device. Are your parameters accurate? Jinghua Pike's flag is against the improper behavior of some friends to exaggerate the parameters of the virtual standard equipment! Jinghua Parker rejects the virtual standard, and the parameter data of the products sold are all measured real data. I am using it abroad, can the voltage be changed? Yes, Jinghua Parker equipment is sold at home and abroad, covering more than 70 countries on five continents. How long is the warranty? One year, our service policy is comprehensive quality assurance, lifelong service Contact information＜Mobile: 0086-13801200210 ＜Phone： 400-888-9616 ＜After-sales service: 031-05079803 ＜Postcode: 102609 ＜Mail Box： equipment@jhpk.net ＜ ＜ProductionCenter: China Electronic Science and Technology Park, Hunnan New District, Hebei Province
