Hydraulic-driven high pressure polyurethane injection equipment JHPK-F16(T)
Product
description
- 产品描述
-
- Commodity name: Hydraulic-driven high pressure polyurethane injection equipment JHPK-F16(T)
- Commodity ID: JHPK-F16（T）
JHPK-F16 polyurethane foaming equipment is the newly series of foaming equipment that launched by Beijing Jinghua Park Polyurethane Equipment Co.Ltd.
Hydraulic-driven high pressure polyurethane injection equipmentJHPK-F16(T)
Product Introduction
JHPK-F16 polyurethane foaming equipment is the newly series of foaming equipment that launched by Beijing Jinghua Park Polyurethane Equipment Co.Ltd.
Compared with the traditional material pump pushing vertically of the traditional equipment, its unique hydraulic driven material pump pushing parallel has solved the problem of seals are damaged by the tilted pump caused by the uneven pressure of two material pumps. The complete, closed, immersed and lubricated material pumps of isocyanate have completely against the air. It has solved the problem that isocyanate crystallizes when comes to the water.
The external heating way of pipe line with ultra thin flat copper wires increases the pipe power so the speed of pipe heating is faster, and the function of heat preservation is more perfect.
Simple, compact machine layout makes the equipment decorous and fashionable. Simple and intuitive operating mechanism saves the steps of resetting the machine over and over again.
Standard Configuration:
Main equipment: 1 set injection gun: 1 piece transfer pumps : 2 pics Heating pipe: 12m Spare parts : 1 set Tools : 1 set English manual: 1 set Package: plywood tray Dimension: 1000mm*1000mm*1550mm Weight: 150Kg Technical Parameter
Ratio of raw materials: 1：1 Viscosity range: 200~1000cps Output of raw materials: 4～12L/min Heating power: 2000W*2 Heating temperature range: 0℃～60℃ Maximum hydraulic driven power: 21Mpa（3045psi） Hydraulic working pressure: 6~8 Mpa（870~1160psi） Power source: 3-phase 4-wires Injection gun cleaning way: Mechanical cleaning Driven way for booster pumps: Hydraulic Driven Driven way for injection gun: Hydraulic Driven
Process / case
Company ProfileJHPK company's main products are polyurethane spraying machine, polyurea spraying machine, polyurethane foaming machine, polyurethane pouring equipment, polyurethane spraying equipment, polyurethane foaming material, polyurethane black and white material, polyurethane resin pultrusion equipment, epoxy resin pultrusion equipment, unsaturated Resin pultrusion equipment, broken bridge aluminum doors and windows filling equipment, polyurethane packaging equipment, feed pump, polyurethane spray gun, polyurethane insulation pipeline, polyurethane road maintenance and lifting equipment, automatic spraying equipment, laboratory polyurethane equipment, tube-in-tube foaming equipment, intelligent two-component spraying equipment, etc.
FAQAre you a factory? How large is the area? headquartered in Beijing, the production center moved to Weinan New District in Hebei in 2018; the production center covers an area of 63,000 square meters, about 100 acres. Is your equipment imported? The mechanical equipment produced by Jinghua Parker is composed of spare parts processed by the processing center imported from the United States, zero-matched by the domestic brand processing center, and Siemens, Schneider and other internationally renowned brand accessories. It is a pure domestic equipment and a national brand. Overseas sales are an important channel for sales of Jinghua Parker products, so the appearance of the equipment is relatively good-looking and is in line with the world. Equipment? Is it installed at home? Free delivery, free on-site installation and commissioning training services for customers in China; free export packaging services for export equipment Why is the product of Jinghua Parker recognized by the market/word of mouth? Because Jinghua Parker starts from the procurement of high-quality raw、 materials, independent processing of spare parts, strict implementation of quality inspection system, traceable finishing process, perfect product display and after-sales service of online and offline process communication, the customer is the core only to build A good mechanical device. Are your parameters accurate? Jinghua Pike's flag is against the improper behavior of some friends to exaggerate the parameters of the virtual standard equipment! Jinghua Parker rejects the virtual standard, and the parameter data of the products sold are all measured real data. I am using it abroad, can the voltage be changed? Yes, Jinghua Parker equipment is sold at home and abroad, covering more than 70 countries on five continents. How long is the warranty? One year, our service policy is comprehensive quality assurance, lifelong service Contact information＜Mobile: 0086-13801200210 ＜Phone： 400-888-9616 ＜After-sales service: 031-05079803 ＜Postcode: 102609 ＜Mail Box： equipment@jhpk.net ＜ ＜ProductionCenter: China Electronic Science and Technology Park, Hunnan New District, Hebei Province
